Leuze BPS 348i - Module 12 - Static Speed Limit Value 2

Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 82
Parameter Rel.
addr.
Data
type
Value
range
De-
fault
Unit Explanation
Metr. Inch
Limit value1
range end
9…12 sign
32 bit
-10,000,00
0…
+10,000,00
0
0 mm in/100 The speed limit value is moni-
tored up to this position.
8.4.14 Module12–Static speed limit value2
Module ID:1012 with submodule ID:1
• The module provides all parameters for the Static speed limit value2 function.
• Further explanations on the Range start and Range end parameters see chapter 8.4.13 "Module11–
Static speed limit value1".
• The module contains parameters (with parameter data length of 13bytes), but no input data and no
output data.
Parameter Rel.
addr.
Data
type
Value range De-
fault
Unit Explanation
Metr. Inch
Switching type 0.0 Bit 0…1 0 ------------- Condition for the Speed
limit value2 signal,
which applies to the
switching output (mod-
ule4/5) and the status bit
(module16):
0: Exceeded
1: Below minimum value
Direction selec-
tion
0.1 Bit 0…1 0 ------------- Selection of the limit
value check:
0: Direction independent
1: Direction dependent
Speed limit
value2
1…2 unsign
16 bit
0…+20,000 0 mm/s (in/100)/s Limit value is compared
to the current speed.
Speed hystere-
sis2
3…4 unsign
16 bit
0…1,000 100 mm/s (in/100)/s Relative shift of the
switching point to pre-
vent signal bouncing.
Limit value2
range start
5…8 sign
32 bit
-10,000,000
…
+10,000,000
0 mm in/100 The speed limit value is
monitored beginning at
this position.
Limit value2
range end
9…12 sign
32 bit
-10,000,000
…
+10,000,000
0 mm in/100 The speed limit value is
monitored up to this posi-
tion.
8.4.15 Module13–Static speed limit value3
Module ID:1013 with submodule ID:1
• The module provides all parameters for the Static speed limit value3 function.
• Further explanations on the Range start and Range end parameters see chapter 8.4.13 "Module11–
Static speed limit value1".
• The module contains parameters (with parameter data length of 13bytes), but no input data and no
output data.
