Leuze BPS 348i - Module 28 - 16-Bit Position Value

Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 91
Input data Rel.
addr.
Data type Value range Init
value
Unit Explanation
Metr. Inch
Increasing tape di-
rection
0.0 BIT 0: Not increasing
1: increasing
0 ------------- The orientation be-
tween BPS and bar
code tape (BCB) re-
sults in an increasing
read direction.
If bits 0.0 and 0.1 are
not set (0), no read di-
rection can currently be
determined.
Decreasing tape
direction
0.1 BIT 0: Not decreas-
ing
1: Decreasing
0 ------------- The orientation be-
tween BPS and bar
code tape (BCB) re-
sults in a decreasing
read direction.
If bits 0.0 and 0.1 are
not set (0), no read di-
rection can currently be
determined.
Input data length: 2bytes
8.4.26 Module28-16-bit position value
Module ID:1028 with submodule ID:1
• Module for the output of the current position value as 16-bit value. The resolution of the position value
is fixed and is one decimeter (100mm) or one inch (in).
• The display of the sign and the measurement unit can be changed in module 1 (see chapter 8.4.3
"Module1–Position value").
• In the default setting, the display is in two's complement and with metric units. If the 16-bit value range
is exceeded, e.g., above an output value of 3.27675km (=32768dm), the value zero (0) is transmitted
as position value in this module.
• The module contains input data (with input data length of 2bytes), but no parameters and no output
data.
Input data Rel.
add
r.
Data
type
Value range Init
val
ue
Unit Explanation
Metr. Inch
16-bit position
value
0 sign
16 bit
With two's comple-
ment:
-32768…32767
With sign and magni-
tude:
-32767…32767
0 dm
(100mm)
inch Position value as 16-bit
value with fixed resolu-
tion of one decimeter
(100mm) or one inch
(in).
Input data length: 2bytes
