Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 88
Input data Rel.
addr.
Data type Value range Init
value
Unit Explanation
Metr. Inch
Distance 0 unsign
8 bit
0…255 0 mm in/10 Current distance be-
tween BCB and read
head:
0: No distance calcu-
lated
255: Distance out-
side of the reading
field
8.4.21 Module22–Control and marker barcodes
Module ID:1022 with submodule ID:1
• The module enables the transmission of control and marker information to the interface master and set-
ting of the corresponding parameters.
• The module contains parameters (with parameter data length of 1byte) and input data (with input data
length of 3bytes), but no output data.
Parameter Rel.
addr.
Data type Value range Default Unit Explanation
Metr. Inch
Reload 0.0 Bit 0…1 0 ------------- Configuration for input
data:
0: Immediately overwrite
input data
1: Overwrite input data
after acknowledgment
Transmission 0.1 Bit field 0…2 0 ------------- Configuration of which in-
formation is transmitted in
the input data:
0: Control and marker
barcodes
1: Only marker barcodes
2: Only control barcodes
Input data Rel.
addr.
Data type Value range Init
value
Unit Explanation
Metr. Inch
First character 0 unsign
8 bit
0…255 0 ------------- First character of the de-
tected control or marker
barcode.
Second char-
acter
1 unsign
8 bit
0…255 0 ------------- Second character of the
detected control or
marker barcode.
Third character 2 unsign
8 bit
0…255 0 ------------- Third character of the de-
tected control or marker
barcode.
8.4.22 Module23–Tape value correction
Module ID:1023 with submodule ID:1
• The module enables the Tape value correction functionality for correcting the deviation of the BCB from
the correct (calibrated) millimeter scaling that results from the manufacturing process.
