Order guide and accessories
Leuze electronic GmbH + Co. KG BPS 348i 124
14.5 Bar code tapes
14.5.1 Standard bar code tapes
Leuze offers a wide selection of standardized bar code tapes.
Tab.14.10: Data for standard bar code tapes
Feature Value
Grid dimensions 30mm (BCBG30…)
40mm (BCBG40…)
Height 47mm
25mm
Length 5m
10m, 20m … in 10m increments up to 150m
200m
Length graduation 10m
Tape start value 0
• Standard bar code tapes are printed below the bar code with the corresponding position value.
• The bar code tapes are wound and delivered on a core.
All available standard tapes are listed on the Leuze website under the currently selected BPS device in the
Accessories tab.
14.5.2 Special bar code tapes
Special tapes are produced according to customer specifications.
Tab.14.11: Data for special bar code tapes
Feature Value
Grid dimensions 30mm (BCBG30…)
40mm (BCBG40…)
Height 20mm–140mm in millimeter increments
Length According to customer specifications, maximum 10,000m
Tape start value According to customer specifications, dependent on grid dimen-
sion
Tape end value According to customer specifications, dependent on grid dimen-
sion, maximum tape end value at 10,000m
• Special bar code tapes are printed below the bar code with the corresponding position value.
• Special bar code tapes over 300m in length are wound and delivered on multiple rolls.
An entry wizard is available for special bar code tapes on the Leuze website under devices BPS300 - Ac-
cessories tab. The entry wizard provides support when entering the individual pieces of tape data and cre-
ates a query or order form with the correct part number and type designation.
