Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 75
Parameter Rel.
addr.
Data
type
Value
range
Default Unit Explanation
Metr. Inch
Input 3 unsign
8 bit
0…3 2 ------------- Internal functionality that is
triggered in the device.
If no internal function is se-
lected, the control can read
the state of an arbitrary ex-
ternal signal via bit 0.0 of the
input data.
0: No internal function
1: Stop/start measurement
2: Teach Preset
3: Reset Preset
Input data Rel.
addr.
Data
type
Value
range
Init value Unit Explanation
Metr. Inc
h
State 0.0 Bit 0…1 --- ------------- Signal state of the input or output:
0: Input/output not active at signal
level
1: Input/output active at signal
level
Output data Rel.
addr.
Data
type
Value
range
Init value Unit Explanation
Metr. Inc
h
Control out-
put
0.0 Bit 0…1 --- ------------- Control of the output. The function
must be activated via the parame-
ters:
0: Output not active at signal level
1: Output active at signal level
NOTICE
Behavior of the BPS during measurement stop/start
If the scanning beam is incident on the BCB at the moment the laser diode is switched on, the
BPS returns valid measurement values after approx. 10ms.
If the BPS is reactivated from standby, the motor must first reach its nominal rotational speed. It
takes a few seconds before the BPS returns any valid measurement values.
8.4.8 Module6–Status and control
Module ID:1006 with submodule ID:1
The module signals various status information of the BPS.
• Various device functions are controlled via the output data.
• The module contains input data (with input data length of 2bytes) and output data (with output data
length of 2bytes), but no parameters.
