Leuze BPS 348i - Module 1 - Position Value

Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 64
Module ID:Profinet_DAP_001
• Common parameters/device-specific parameters (DAP: Device Access Point):
• The module contains device-specific parameters, but no input data and no output data.
Parameter Rel. addr. Data
type
Value
range
Default Unit Explanation
Metr. Inch
Profile 0 Byte 1 1 -------------- Defines the used device pro-
file.
Note:
Currently, only the BPS pro-
file is stored. Thus, no selec-
tion is possible.
Number of the activated pro-
file.
1: BPS profile
Integration
depth
1.0…1.4 Bit field 2…16 8 Measure-
ments
Number of successive mea-
surements that the BPS
uses for position determina-
tion.
Tape selection 1.5…1.6 Bit field 1: 30mm
(BCBG30
…)
2: 40mm
(BCBG40
…)
2 -------------- Changeover between
barcode tape with 30mm
grid (BCBG30…) and
40mm grid (BCBG40…).
8.4.3 Module1–Position value
Module ID:1001 with submodule ID:1
• Module for the output of the current position value. The module also includes the most important pa-
rameters for formatting the output value.
• The module contains parameters (with parameter data length of 6bytes) and input data (with consis-
tent input data length of 4bytes), but no output data.
Parameter Rel.
addr.
Data
type
Value range De-
fault
Unit Explanation
Metr. Inch
Sign 0.0 Bit 0…1 0 ------------- Output mode of the sign. Af-
fects position value and
speed output:
0: Two's complement
1: Sign+quantity
Unit 0.1 Bit 0…1 0 ------------- The selection of the mea-
surement unit affects all val-
ues with measurement
units. The parameter ap-
plies to all interfaces:
0: Metric (mm)
1: Inch (in)
