8.4.6 Module4–Input/output IO1
Module ID:1004 with submodule ID:1
• This module is used to set the mode of operation of digital input/output IO1. The connection can be
used as either an input or an output.
• The output is activated by various events in the device.
• If used as an input, a device function is controlled by an external signal.
• Alternatively, the connection can also be used decoupled from the device:
• If used as an input, the state of an external signal is transmitted to the control in the input data.
• If used as an output, the connection is operated via the output data.
• The module contains parameters (with parameter data length of 4bytes), input data (with input data
length of 1byte) and output data (with output data length of 1byte).
Parameter Rel.
addr.
Data
type
Value
range
Default Unit Explanation
Metr. Inch
Function 0.0 Bit 0…1 1 ------------- Mode:
0: Input
1: Output
Activation 0.1 Bit 0…1 1 ------------- The parameter defines the
level of the output at which the
Output event occurs.
0: LOW (output), transition
1→0
1: HIGH (output), transition
0→1
If the I/O is configured as an
input, it responds edge-trig-
gered.
