Leuze BPS 348i - Module 2 - Static Preset

Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 65
Parameter Rel.
addr.
Data
type
Value range De-
fault
Unit Explanation
Metr. Inch
Position
resolution
0.2…0.4 Bit 1…6 4 mm in/100 Resolution of the position
value. Affects only the inter-
face-specific output. The
resolution has no effect on
the set parameter values
such as offset or preset:
001=1: 0.001
010=2: 0.01
011=3: 0.1
100=4: 1
101=5: 10
110=6: Free resolution
Counting
direction
0.5 Bit 0…1 0 ------------- Count direction for position
calculation or sign for speed
calculation. The parameter
affects all interfaces:
0: Positive
1: Negative
Offset 1…4 sign
32 bit
-10,000,000…
+10,000,000
0 mm in/100 Output value=measurement
value+offset.
The parameter affects all in-
terfaces.
Note:
If a preset is active, this has
priority over the offset.
Input data Rel.
addr.
Data
type
Value range Init
value
Unit Explanation
Met
r.
Inch
Position 0.0 sign
32 bit
-2.000.000.000…
+2,000,000,000
0 Scaled Current position.
NOTICE
Convert numerical values when changing the unit of measurement!
Ä If the unit of measurement is changed from metric to inch (or vice versa), previously entered
numerical values (e.g. for offset, preset, limit values etc.) are not automatically converted.
Example: Offset = 10000mm
after changing from metric to inch: Offset = 10000inch/100
Ä Manually convert the numerical values when changing the unit of measurement.
8.4.4 Module2–Static preset
Module ID:1002 with submodule ID:1
• With the module, it is possible to specify a static preset as a parameter and to activate this preset value
at a suitable position (Teach Preset). The preset value is deactivated using the Reset Preset function. If
the preset is activated, a set offset (module1) is not used for the calculation of the position value (mod-
ule1).
• An activated preset is stored in the BPS and in the connection hood. In the event of a device exchange,
the values in the connection hood are retained. In the event of a device exchange including the connec-
tion hood, the preset value must be reactivated at the intended position (Teach Preset).
