Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 71
Parameter Rel.
addr.
Data
type
Value
range
Default Unit Explanation
Metr. Inch
Input 3 Bit field 0…3 0 Internal functionality that is
triggered in the device.
If no internal function is se-
lected, the control can read the
state of an arbitrary external
signal via bit 0.0 of the input
data.
0: No internal function
1: Stop/start measurement
2: Teach Preset
3: Reset Preset
Input data Rel.
addr.
Data
type
Value
range
Init
value
Unit Explanation
Metr. Inch
State 0.0 Bit 0…1 --- ------------- Signal state of the input or out-
put:
0: Input/output not active at
signal level
1: Input/output active at signal
level
Output data Rel.
addr.
Data
type
Value
range
Init
value
Unit Explanation
Metr. Inch
Control output 0.0 Bit 0…1 --- ------------- Control of the output. The function
must be activated/deactivated via
the parameters:
0: Output not active at signal level
1: Output active at signal level
NOTICE
Behavior of the BPS during measurement stop/start
If the scanning beam is incident on the BCB at the moment the laser diode is switched on, the
BPS returns valid measurement values after approx. 10ms.
If the BPS is reactivated from standby, the motor must first reach its nominal rotational speed. It
takes a few seconds before the BPS returns any valid measurement values.
8.4.7 Module5–Input/output IO2
Module ID:1005 with submodule ID:1
This module is used to set the mode of operation of digital input/output IO2. The connection can be used
as either an input or an output.
• The output is activated by various events in the device.
• If used as an input, a device function is controlled by an external signal.
• Alternatively, the connection can also be used decoupled from the device:
• If used as an input, the state of an external signal is transmitted to the control in the input data.
• If used as an output, the connection is operated via the output data.
• The module contains parameters (with parameter data length of 4bytes), input data (with input data
length of 1byte) and output data (with output data length of 1byte).
