Leuze BPS 348i - Page 72

Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 72
Parameter Rel.
addr.
Data
type
Value
range
Default Unit Explanation
Metr. Inch
Function 0.0 Bit 0…1 0 ------------- Mode:
0: Input
1: Output
Activation 0.1 Bit 0…1 1 ------------- The parameter defines the
level of the output at which
the Output event occurs.
0: LOW (output), transition
1→0
1: HIGH (output), transition
0→1
If IO2 is configured as an in-
put, it responds edge-trig-
gered.
Output Event for activating the out-
put. The individual functions
are OR-linked to one an-
other.
1.0 Bit 0…1 0 ------------- Position limit value1:
If the position value lies out-
side of configured Limit value
range1, the output is set:
0: OFF
1: ON
1.1 Bit 0…1 0 ------------- Position limit value2:
If the position value lies out-
side of configured Limit value
range2, the output is set:
0: OFF
1: ON
1.2 Bit 0…1 0 ------------- Speed limit value:
If the speed value lies out-
side of the configured values,
the output is set.
0: OFF
1: ON
1.3 Bit 0…1 0 ------------- Position value invalid:
If no valid position value can
be ascertained because,
e.g., no barcode tape is read
or the barcodes are de-
stroyed or soiled, the output
is set.
0: OFF
1: ON
1.4 Bit 0…1 0 ------------- Speed value invalid:
The output is set if no valid
speed can be calculated.
0: OFF
1: ON
