Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 73
Parameter Rel.
addr.
Data
type
Value
range
Default Unit Explanation
Metr. Inch
Output Event for activating the out-
put. The individual functions
are OR-linked to one an-
other.
1.5 Bit 0…1 0 ------------- Warning threshold reading
quality:
If the ascertained reading
quality is below the config-
ured warning threshold, the
output is set.
0: OFF
1: ON
1.6 Bit 0…1 0 ------------- Error threshold reading
quality:
If the ascertained reading
quality is below the config-
ured error threshold, the out-
put is set.
0: OFF
1: ON
1.7 Bit 0…1 0 ----------- Marker bar code or control
bar code detected
If a marker bar code or a
control bar code is located in
the scanning beam, the out-
put is set.
0: OFF
1: ON
