Electrical connection
Leuze electronic GmbH + Co. KG BPS 348i 50
NOTICE
The function as an input or output is set via PROFINET parameters (Setting the bus address) or
using the webConfig configuration tool (CONFIGURATION > DEVICE > Switching inputs/out-
puts, (see chapter 9.3.4 "CONFIGURATION function").
If SWIO1 or SWIO2 is to be used as digital input or output, the configuration must be performed
in module4 (see chapter 8.4.6 "Module4–Input/output IO1") or module5 (see chapter 8.4.7
"Module5–Input/output IO2").
NOTICE
Maximum input current
Ä The input current of the respective switching input is maximum 8mA.
NOTICE
Maximum loading of the switching outputs
Ä Do not load the respective switching output of the BPS with more than 60mA at
+18…30VDC in normal operation.
Ä Each configured switching output is short-circuit proof.
NOTICE
The two switching inputs/outputs, SWIO1 and SWIO2, are configured as follows by default:
Switching output SWIO1: Position value invalid
Switching input SWIO2: Teach Preset
NOTICE
SWIO1 and SWIO2 as switching output
Ä At the outputs of the BPS (SWIO1 and SWIO2), no switching outputs may be connected
from external sensors/devices.
The switching output of the BPS may otherwise malfunction.
