Starting up the device – Basic configuration
Leuze electronic GmbH + Co. KG BPS 348i 86
Input data Rel.
addr.
Data
type
Value
range
Init value Unit Explanation
Metr. Inch
Speed limit value3
exceeded
0.3 Bit 0…1 --- ------------- Signals that speed limit
value3 has been ex-
ceeded:
0: No limit value violation
1: Value greater than limit
Speed limit value4
exceeded
0.4 Bit 0…1 --- ------------- Signals that speed limit
value4 has been ex-
ceeded:
0: No limit value violation
1: Value greater than limit
Dynamic speed
limit value ex-
ceeded
0.5 Bit 0…1 --- ------------- Signals that the dynamic
speed limit value has
been exceeded:
0: No limit value violation
1: Value greater than limit
Movement status 0.6 Bit 0…1 --- ------------- Signals whether a move-
ment >0.1m/s is cur-
rently being detected:
0: No movement
1: Movement
Direction of move-
ment
0.7 Bit 0…1 --- ------------- If bit1 (movement status)
is set, this bit indicates
the direction:
0: Positive direction
1: Negative direction
Speed limit value1
active
1.1 Bit 0…1 --- ------------- Signals whether the cur-
rent speed is compared
with the Speed limit
value1:
0: Comparison not active
1: Comparison active
Speed limit value2
active
1.2 Bit 0…1 --- ------------- Signals whether the cur-
rent speed is compared
with the Speed limit
value2:
0: Comparison not active
1: Comparison active
Speed limit value3
active
1.3 Bit 0…1 --- ------------- Signals whether the cur-
rent speed is compared
with the Speed limit
value3:
0: Comparison not active
1: Comparison active
Speed limit value4
active
1.4 Bit 0…1 --- ------------- Signals whether the cur-
rent speed is compared
with the Speed limit
value4:
0: Comparison not active
1: Comparison active
