Replacing the pick roller assembly and the separator pick roller
112
Maintenance
Replacing the pick roller assembly and the separator
pick roller
You need to replace these items when you have scanned 40,000 pages.
To replace them:
1 Turn the MFP off.
2 Open the top cover of the ADF.
3 Grasp the plastic part of the used pick roller assembly on each side.
4 Push the pick roller assembly to the side of the ADF, so one side of the assembly is loose.
