Removing optional cards
144
Administration
Reattaching the side door
1 Align the three tabs on the back of the side door with the slots on the MFP.
2 Align the tabs on the bottom of the side door with the slots at the bottom of the MFP.
3 Press the side door firmly into place, making sure that the two tabs are in place, and that the
ridge on top of the side door aligns with the ridge on the MFP.
Ridge
Tab s
