Print media specifications and guidelines
69
Media specifications and guidelines
5 Squeeze the length guide tab and the length guide together, and then slide the guide to the
back of the tray.
6 Squeeze the width guide tab and the width guide together, and then slide the guide all the
way to the right.
7 Flex the sheets back and forth to loosen them, and then fan them. Do not fold or crease the
paper. Straighten the edges on a level surface.
Hold the paper so the side you want to print on is face down, and the front edge of the stack
is toward the front of the tray.
For information on loading letterhead, see Printing on letterhead.
Length guide
Width guide
