| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 11
Figure 4 Front-terminal battery system configurations
62"
(1575mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
15-½"
Junction
Cabinet
(May be on
either end
or between
any battery
cabinets)
625-750kVA
Stand-Alone
Interconnected
Systems
625-1200kVA
One or more battery cabinets
bolted to the UPS
Battery cabinets must be on the
left side of the UPS.
62"
(1575mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
17-½"
Junction
Cabinet
(May be on
either end
or between
any battery
cabinets )
800-1200kVA
Stand-Alone
Interconnected
Systems
62"
(1575mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
S
p
a
c
e
r
Liebert
UPS
