| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 42
Table 10 Input Contact Isolator Board pre-assigned values
Channel #
ICI #1 ICI #2
Pre-Assigned Label Pre-Assigned Label
1 Reduced Rect ILimit None
2 Reduced Batt ILimit None
3 Stop Battery Charge None
4— None
5 EcoMode Suspended None
6— None
7— None
8— None
Table 11 Input Contact Isolator Board control wiring connections
Input Contact Pin No.
1
1
2
2
3
4
3
5
6
4
7
8
5
9
10
6
11
12
7
13
14
8
15
16

Liebert EXL Specifications

General

Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Efficiency	Up to 99%
Input Voltage	480V
Output Voltage	480V
Topology	Double Conversion
Form Factor	Tower
Battery Type	VRLA, Lithium-ion
Communication Interface	RS-232, USB
Humidity	0-95% non-condensing
