F
F
CORE TO CORE BUSBARS
(2) SIDE BY SIDE FOR BATT NEG (-)
(2) SIDE BY SIDE FOR BATT POS (+)
3
4
2
3
3
2
3
4
Route harness from input in duct to
Core 1 (connectors - J400, J11, J12)
bypass (connectors - J100, J200, J300)
Core 1, 2 & 3 prechg (See Section F-F)
Connect to input harness
(Connectors P400, P11)
Connect to input harness
(Connectors P12)
Route harness from bypass
in duct to input
(Connectors P100, P200, P300)
Rear
Wiring Duct
Front
Wiring Duct
Connected together in rear duct.
Route harness from bypass in
duct to input (Connector - P20)
Core 1
Core 2
Core 1
Core 2
Core 3
Core 3
Input (Connector HVAB
P20) See Sheet 3
Route harness from input in duct to
Core 1 (Connectors -P1, P2, P3, P66)
Core 2 (Connectors - P1, P2, P3)
Core 3 (Connectors - P1, P2, P3)
Bypass (Connectors - P99A, P1)
Rear Wire Duct
From Input
Core 1 Prechr Ph A
(Brown Wire)
Core 3 Prechr Ph A
(Brown Wire)
Core 2 Prechr Ph A
(Brown Wire)
Core 1 Prechr Ph B
(Orange Wire)
Core 2 Prechr Ph B
(Orange Wire)
Core 3 Prechr Ph B
(Orange Wire)
Batt Neg (-) & Batt Pos(+) Flex
from Input Cabinet
Installed in Factory
Installed in Factory
Installed in Factory
x 6
4
x 6
2
x 6
x 8
x 6
x 8
x 8
2x 6
3x 8
Core 1
Core 2
Core 3
AC Input Flex from Input Cabinet
Core-to-Core Busbars
1 per Phase
Core-to-Core Busbars
1 per Phase
AC Output Flex
from Bypass Cabinet
Cabinet-to-Cabinet Power Connections
Typical Flex to Core Busbar Hardware
M8 Large Flat Washer (1) {PN: 09-43E00Z-00}
M8 Belleville Washer (2) {PN: 09-39D00Z-A7}
M8 X 50 Bolt (1) {PN: 09-02EL0Z-16}
Torque 180 in-lb (20 Nm)
Typical Single Core to Core Busbar Hardware
M8 Large Flat Washer (1) {PN: 09-43E00Z-00}
M8 Belleville Washer (2) {PN: 09-39D00Z-A7}
M8 X 35 Bolt (1) {PN: 09-02EL0Z-13}
Torque 180 in-lb (20 Nm)
Typical Double Core to Core Busbar Hardware
M8 Large Flat Washer (1) {PN: 09-43E00Z-00}
M8 Belleville Washer (2) {PN: 09-39D00Z-A7}
M8 X 40 Bolt (1) {PN: 09-02EL0Z-14}
Torque 180 in-lb (20 Nm)
BATT Pos (+)
BATT Neg (-)
BATT Neg (-)
BATT Neg (-)
BATT Pos (+)
AC Ph-A
AC Ph-B
AC Ph-C
AC Ph-A
AC Ph-B
AC Ph-C
AC Ph-C
AC Ph-B
AC Ph-A
SECTION F-F
J100
J200
J300
J11
J400
J12
Bypass
Bypass
Bypass
Core 1
Core 1
Core 3
P100
P200
P300
P11
P400
P12
Rear
Rear
Rear
Rear
Rear
Rear
Input
Input
Input
Input
Input
Input
Cabinet
Start
Cabinet
Finish
Connector
Label
Connector
Label Duct
Core Prechg Ph A
Core Prechg Ph B
Core Prechg Ph A
Core Prechg Ph B
Core 1 Prechg Ph A
Core 1 Prechg Ph B
Core 3 Prechg Ph A
Core 3 Prechg Ph B
Core 2 Prechg Ph A
Core 2 Prechg Ph B
Rear
Rear
Rear
Rear
Input
Input
Input
Input
Cabinet
Start
Cabinet Finish
Connector Label
Connector Label
Duct
To Next Page
