| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 12
Figure 5 Front-terminal stand-alone battery system configuration
Figure 6 Front-terminal battery system configuration—Battery cabinets not attached to UPS or each other
62"
(1575mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
62"
(1575 mm)
Battery
Cabinet
62"
(1575mm)
Battery
Cabinet
Stand-Alone
Individual
Systems
Liebert
UPS
Detached
Junction
Cabinet
32"
(813mm)
62"
(1575mm)
Battery
Cabinet
62"
(1575 mm)
Battery
Cabinet
Stand-Alone
Individual
Systems
