| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 60
Figure 40 Kickplate installation—1000-1200kVA, single module units
555130P1
Pg. 1, Rev. 0
RIGHT HAND FRONT
LEFT HAND REAR
Panel Rear
Bottom
Panel Rear
Bottom
Panel Rear
Bottom
Panel Rear
Bottom
Panel Rear
Bottom
Panel Side
Bottom
Panel Side
Bottom
Panel Front
Bottom
Panel Front
Bottom
Panel Front
Bottom
Panel Front
Bottom
Panel Front
Bottom
M10 Lock Washer,
Split ZP, Typical
Screw Cap HH
M10‐1.5x25mm ZP
Hexagonal Cap
Black M10 (17mm)
Typical
M10 Flat
Washer ZP, Typical
