| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 51
Battery
UPS Rating
Voltage
VAC
Cable
Entry
(# of conduits); size of conduits; # -size of phase cables per conduit;
size of cable for ground per conduit
kVA kW Copper Conductors Aluminum Conductors
625 625
480
Top (5)3"C 2-600kcmil; 250kcmil (6) 3"C 2-600kcmil; 400kcmil
Bottom (5)3"C 2-600kcmil; 250kcmil (6) 3.5"C 2-600kcmil; 400kcmil
750 750
Top (5)3"C 2-600kcmil; 250kcmil (6) 3"C 2-600kcmil; 400kcmil
Bottom (5)3"C 2-600kcmil; 250kcmil (6) 3.5"C 2-600kcmil; 400kcmil
800 800
Top (6)3"C 2-600kcmil; 350kcmil (7) 3"C 2-700kcmil; 600kcmil
Bottom (6)3"C 2-600kcmil; 350kcmil (7) 3.5"C 2-700kcmil; 600kcmil
1000 1000
480
Top (8)3"C 2-600kcmil; 500kcmil (8) 3"C 2-700kcmil; 600kcmil
Bottom (8) 3.5"C 2-600kcmil; 500kcmil (8) 3.5"C 2-700kcmil; 600kcmil
1100 1100
Top (8)3"C 2-600kcmil; 500kcmil (8) 3"C 2-700kcmil; 600kcmil
Bottom (8) 3.5"C 2-600kcmil; 500kcmil (8) 3.5"C 2-700kcmil; 600kcmil
1200 1200
Top (9)3"C 2-750kcmil; 500kcmil (11) 3"C 2-700kcmil; 750kcmil
Bottom (9) 3.5"C 2-750kcmil; 500kcmil (11) 3.5"C 2-700kcmil; 750kcmil
1. Recommended cable sizes are 167°F (75°C) (THW) wire at 86°F (30°C) ambient.
2. Refer to NEC recommendations for 104°F (40°C) ambient rated conductors.
3. Unless otherwise noted, use copper or aluminum conductors suitable for at least 75°C.
4. Recommended cables and conduits are based on breaker trip setting sized for the maximum continuous rated current for the rectifier input and
the nominal current for the bypass and output listed in Tables 14 through 17.
5. Conduit size is based on RNC type conduit for bottom input and EMT-type conduit for top input.
6. Vertiv® recommends that the site planner choose the appropriate cable type based on the particular installation requirements.
7. These recommendations are for use with 100% rated breakers. For 125% rated breakers, refer to the NEC recommended conduit and cable sizes.
8. Upstream and downstream non-standard recommended breaker settings have their trip adjustment behind a suitable cover in accordance with
240.6(c) of the NEC.
Table 19 Recommended breakers, upstream and downstream
UPS Rating
kVA
System Input
Nominal Current
Recommended External
Breaker Trip, Amps
Upstream Breakers
625 777 900
750 933 1000
800 995 1200
1000 1246 1400
1100 1371 1600
1200 1496 1600
Downstream Breakers
625 752 800
750 902 1000
800 962 1000
1000 1203 1400
1100 1323 1400
1200 1443 1600
Table 18 Recommended conduit and cable sizes for use with 100% rated breakers (continued)
