| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 34
Figure 21 Base drawing, 1000-1200kVA Liebert EXL UPS, SMS and 1+N multi-module unit
23.8 (605)
Opposite Side
Typical
NOTES:
1. All dimensions are in inches (mm).
2. Unit bottom is structurally adequate for forklift handling.
Input
Core
Core
Core
Output/Bypass
18.8
(478)
18.8
(478)
18.8
(478)
18.8
(478)
18.5
(470)
18.5
(470)
18.5
(470)
40.7 (1035)
3 (99)
Opposite
Side
Typical
FRONT VIEW
Forklift Openings Forklift Openings
20.5
(520)
20.5
(520)
20.5
(520)
31.3 (795)
Pillar Spacing
Outside
25.6 (651)
Pillar Spacing
Inside
30.8 (781)
Foot Spacing
Outside
23.8 (605)
Foot Spacing
Inside
Opposite
Side
BOTTOM OUTPUT
Right Side
Bottom Cable Entry Panels
BOTTOM VIEW
(Top Looking Down)
Footprint Spacing
2.8 (70)
Foot to Pillar
3.1
(80)
6.3
(160)
6.3
(160)
7.1
(180)
7.1
(180)
RIGHT SIDE
Lift Clearance
U46-12L-1000
Rev. 0
2.8 (70)
Foot to Pillar
Front
Front
6.1 (155)

Liebert EXL Specifications

General

Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Efficiency	Up to 99%
Input Voltage	480V
Output Voltage	480V
Topology	Double Conversion
Form Factor	Tower
Battery Type	VRLA, Lithium-ion
Communication Interface	RS-232, USB
Humidity	0-95% non-condensing
