| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 55
Table 24 Connections associated with sections in “View” column
Cabinet
Start
Connector
Label
Cabinet
Finish
Connector Label
(Connect This End) Duct View
Bypass CT7-CT9 Input P20 HVAB Front Section F-F
Input P50 Bypass P1 Bypass Connector Board Front Section G-G
Input P66A Bypass P99A CB2 I/F BD Front Detail H
Input P11 Core 1 P1 Core Connector Board Front Detail E
Input P12 Core 1 P2 Core Connector Board Front Detail E
Input P1 Core 1 P3 Core Connector Board Front Detail E
Input P99 Core 1 P66 FIB 1 Front Detail E
Input P21 Core 2 P1 Core Connector Board Front Detail E
Input P22 Core 2 P2 Core Connector Board Front Detail E
Input P2 Core 2 P3 Core Connector Board Front Detail E
Bypass P66 Core 1 P99 FIB 1 Front Detail E

Liebert EXL Specifications

General

Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Efficiency	Up to 99%
Input Voltage	480V
Output Voltage	480V
Topology	Double Conversion
Form Factor	Tower
Battery Type	VRLA, Lithium-ion
Communication Interface	RS-232, USB
Humidity	0-95% non-condensing
