Liebert EXL User Manual

Vertiv
™
| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 45
Height, in (mm) 77.5 (1969) 77.5 (1969)
Weight, Unpackaged, lb. (kg)
approximate with Static Bypass (1+N)
5687 (2580) 8095 (3672)
Maximum Heat Dissipation, Full Load, BTU/hr (kW)
625kVA UPS: 77,417 (22.7) 1000kVA UPS: 123,867 (36.3)
750kVA UPS: 95,653 (28.0) 1100kVA UPS: 136,253 (39.9)
800kVA UPS: 102,030 (29.9) 1200kVA UPS: 148,640 (43.5)
Cooling Air, CFM ≤4,600 ≤6,700
Color Black (ZP-7021) Black (ZP-7021)
Front Door Opening (for serviceability) 90° 90°
Degree of Protection for UPS Enclosure IP 20 (with and without front door open) IP 20 (with and without front door open)
Minimum Clearance, Top, in (mm) 24 (610) 24 (610)
Minimum Clearance, Back, in (mm) 0 0
Minimum Clearance, Sides, in (mm) 0 0
Location of Cable Entrance Top or Bottom Top or Bottom
Standards and Conformities
UL 1778, 5th Ed.
CSA 22.2 107.3
FCC Part 15, Class A
(with optional filters installed)
IEC62040-2, Level 4, Criteria A
ANSI C62.41, Category A3 &B3
ISTA
WEEE
UL 1778, 5th Ed.
CSA 22.2 107.3
FCC Part 15, Class A
(with optional filters installed)
IEC62040-2, Level 4, Criteria A
ANSI C62.41, Category A3 &B3
ISTA
WEEE
Environmental Parameters
Storage Temperature Range, °F (°C) -4 to 104 (-20 to 40)
3
-4 to 104 (-20 to 40)
3
Operating Temperature Range, °F (°C)
32°F to 95°F (0°C to 35°C) at
full rated load
1.5% maximum kW / degrees C derating up
to 50°C
122°F (50°C) absolute maximum with
derating
32°F to 95°F (0°C to 35°C) at
full rated load
1.5% maximum kW / degrees C derating up
to 50°C
122°F (50°C) absolute maximum with
derating
Relative Humidity
95% or less Non-Condensing
(Operating and Non-Operating)
95% or less Non-Condensing
(Operating and Non-Operating)
Maximum Altitude Above MSL
3300 ft.(1000m) (per IEC 62040/3) - 1%
Maximum kW derating / 1000 ft. rise
between 3300 and 10,000 ft. (305m rise
between 1000 and 3000m)
3300 ft. (1000m) (per IEC 62040/3) - 1%
Maximum kW derating / 1000 ft. rise
between 3300 and 10,000 ft. (305m rise
between 1000 and 3000m)
1. Width dimensions are with side panels attached. Subtract 1.4" (35mm) for dimensions without side panels.
2. Depth dimensions include the front door and rear panel.
3. Contact the factory before storing at temperatures exceeding 104°F (40°C)
Table 14 Current ratings—rectifier input
UPS Rating
Voltage
VAC
Nominal
Current
Maximum
CurrentkVA kW
625 625 480 779 818
Table 13 Liebert EXL UPS specifications (continued)
Model Size
625-800kVA 1000-1200kVA

Liebert EXL Specifications

General

Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Efficiency	Up to 99%
Input Voltage	480V
Output Voltage	480V
Topology	Double Conversion
Form Factor	Tower
Battery Type	VRLA, Lithium-ion
Communication Interface	RS-232, USB
Humidity	0-95% non-condensing
