Liebert EXL - Figure 33 Bypass Overload Data

Vertiv
™
| Liebert® EXL™ 625-1100kVA Installation Manual | Rev. 3 | 02/17 49
Figure 33 Bypass overload data
324.8
194.7
120.0
75.9
49.0
32.4
21.8
14.9
10.4
7.3
5.2
3.8
2.8
2.1
1.5
1.2
0.9
0.2
500.0
0.0
50.0
100.0 150.0 200.0 250.0 300.0 350.0 400.0 450.0 500.0
100% 110% 120% 130% 140% 150% 160% 170% 180% 190% 200%
% Load
Time (sec)
Continuous
