Liebert Vertiv GXT5 User Manual

Specications114
MODEL GXT5-
1
6KIRT9UXLN* 16KIRT9UXLE
2
0KIRT9UXLN* 20KIRT9UXLE
RATING 16000 VA/16000 W 20000 VA/20000 W
Output AC Parameters
AC-AC Eiciency
U
p
to
95
.9%
Factory-default
VAC Frequency
230 VAC, 50 Hz
Output Power
Connection
Output terminal block
Waveform Sinewave
Main Mode
Overload
> 150% minimum 200 mS, 125 to 150% for 60 seconds;
105 to 125% for for 5 minutes; ≤ 105% continuous
User- congurable
VAC
200/208/220/230/240 VAC
(Adjustable using operation/display conguration options)
Bypass parameters
Upper-limit
selections
+10%, +15%, +20%; default +10%.
Lower-limit
selections
-10%, -15%, -20%; default -15%
Disable-bypass
operation
When the input frequency prevents synchronous operation.
Internal Battery Charger
Charger Current, A default 2.25 A, maximum 13 A
Battery Parameters
Type Valve-regulated, non-spillable, lead acid
Qty×V×Rating 32 x 12V x 9.0 AH
Battery Mfr./Part# 9 AH; LEOCH/DJW12-9.0
Back-up time See Battery Run Times on page 122. See Battery Run Times on page 123.
Environmental Requirements
Operating
Temperature,
°F (°C)
0 to 40 (32 to 104) (no derating)
Storage
Temperature,
°F (°C)
-20 to +60 (-4 to +140) ( contain batteries will be from -15 to 40 °C.)
Relative Humidity 0 to 95% non-condensing
Operating
Elevation
Up to 3,000 m (9,842.5 ft) at 25°C (77°F) without derating
Audible Noise Front and Side <58 dBA

Liebert Vertiv GXT5 Specifications

General

Output Voltage	230V
Topology	Double Conversion Online
Frequency	50/60 Hz
Operating Temperature	0°C to 40°C
Dimensions	Varies by model
Weight	Varies by model
Form Factor	Rack/Tower
Battery Type	Valve Regulated Lead Acid (VRLA)
Communication Ports	USB, RS-232
Efficiency	Up to 95%
Typical Recharge Time	3 hours to 90%
Storage Temperature	-15°C to 40°C
Humidity	0% to 95% non-condensing
