FRC FLC RR RL FC LFE FR FL
Legend:
FR / FL Front Right / Front Left
LFE Low-frequency effect
FC/RC Front Center / Rear Center
RR/RL Rear Right / Rear Left
FRC/FLC Front Right Center / Front Left Center
RRC/RLC Rear Right Center / Rear Left Center
Please note that the values of c, d, ee and ff fields are based on the
audio InfoFrame sent by the source device while values of a, b are
based on measurements. Of course audio InfoFrames are forwarded in
unchanged form to the HDMI sink devices (e.g. A/V Receivers) so that
they would be able to interpret the InfoFrames correctly.
Example: A1C010600; (two channel 48kHz PCM)
Note: This block is present only if an HDMI signal is available on the
selected port.
4.5.5.4. Advanced info block
Format: Iabcdef
For advanced users this block provides information which could be
useful during debugging process. The first character of this block must
be ’I’. The meanings of the following characters are:
a: 0 - VSYNC polarity is negative (leading edge falls)
1 - VSYNC polarity is positive (leading edge rises)
b: 0 - HSYNC polarity is negative (leading edge falls)
1 - HSYNC polarity is positive (leading edge rises)
c: 0 - There is no change on the TMDS clock line
1 - Signal is present on the TMDS clock line
d: 0 - The clock signal is unstable on the TMDS clock line
1 - The clock signal is stable on the TMDS clock line
