MX32x32DVI-HDCP-Pro and HDMI-Pro
User’s Manual v1.0
Page 61/ 109
e: Active Format Aspect Ratio based on AVI InfoFrame
0 Field is not present (e.g. DVI signal)
2 16:9 (top)
3 14:9 (top)
4 greater than 16:9 (centre)
5 Same as picture aspect ratio
9 4:3 (centre)
A
16:9 (with shoot and protect 4:3 centre)
f: Pixel repetition factor based on AVI InfoFrame
0 No repetition (i.e. pixel sent once)
1 Pixel sent 2 times (i.e. repeated once)
3 Pixel sent 4 times
Example: I111190;
(positive HSYNC and VSYNC, stable pixel clock, 4:3 aspect
ratio and no pixel repetition)
4.5.5.5. Input settings block
Format: Pab;
You are able to verify the actual settings on the selected input ports with
this block. This block is always present. The first character is ’P’, the
next characters are:
a: The cable equalization level at this input. The possible values
are:
0 Automatic cable equalization
1 Equalization is 3dB
2 Equalization is 9dB
3 Equalization is 25dB
4 Equalization is 35dB
5 Equalization is 40dB
b: The state of color range compression. The values are the
same as described in the 4.5.7 section.
Example: PAA;
(Automatic cable equalization and color range conversion is disabled)
