LS SERIES SERVICE MANUAL
ISSUE 4.0 FULL CONTROL CONSOLE DIAGNOSTICS 12
Select External Device to Calibrate
XXXXX
< >
3 Select the required extensometer (if more than 1 extensometer is connected to the
machine) then press the ENTER key.
Calibrate External Device
Serial
Number Type Set Calibrate
XXXX XXXX Detail or Verify
4 Press the key under CALIBRATE OR VERIFY to display the screen shown below: -
Serial Number XXXXX Type XXXXX
Measured Ext XXXX mm
Clear Cal View View
Points Point Points Readings
5 Press the key under CLEAR POINTS then press the key under YES to erase ALL previous
calibration data.
6 Attach the extensometer to the calibration device and set the calibration device to zero
extension.
7 Press the key under CAL POINT to display the Cal Point screen.
True Ext XXXXX N
Measured Ext XXXXX N
Change Accept
True Tension Cancel
8 Press the key under ACCEPT TENSION to store the zero point into the extensometer
EEPROM then redisplay the previous screen.
9 Press the Zero key on the control console to zero the machine's extension display.
10 Move the calibration device to the first required position then record the extension value
displayed on the console.
11 If the displayed extension reading is NOT within specification, enter a calibration point by
pressing the key under CAL POINT to display the Cal Point screen.
