LS SERIES SERVICE MANUAL
ISSUE 4.0 FULL CONTROL CONSOLE DIAGNOSTICS 13
True Ext XXXXX N
Measured Ext XXXXX N
Change Accept Accept
True Tension T+C Cancel
12 The value displayed for the True Extension will be automatically set to the nearest 1%,
5% or 10%. If the indicated True Extension is not as required, press the key under
CHANGE TRUE then enter the required True Extension value.
13 Press the key under ACCEPT TENSION to store the calibration point into the
Extensometer EEPROM then redisplay the previous screen.
14 Continue the calibration by moving the calibration device at the required intervals up to
the full range of the extensometer, entering calibration points as necessary.
NOTE:-
A single calibration point may be deleted by pressing the key under DELETE when on the
VIEW POINTS screen.
