107
User Manual
B
Smart DGPS WAAS Receiver
The Smart DGPS WAAS receiver is based on a ultimate 12 channel GPS
engine that delivers accuracy better than three meters by decoding the GPS correc-
tion signals from the satellite-based WAAS (Wide Area Augmentation System). The
GPS engine, interface electronics and the passive antenna are enclosed inside the
water-proof plastic housing. This provides advanced state of the art GPS perfor-
mance in an easy to use package.
Note
The characteristics of your Receiver could not be the same as the following explained. Contact the
dealer the chartplotter was purchased from for more information.
B.1 TECHNICAL SPECIFICATIONS
B.1.1 PYSICAL CHARACTERISTICS
Color : Ivory white
Dimensions : 97mm in diameter x 32mm in height (flush mounted) or
61,5mm on flag-pole mount
Weight : 160 grams (without cable)
Cable : white 15 meter 8x28AWG cable
B.1.2 ELECTRICAL CHARACTERISTICS
Input Voltage : 10 Vdc to 35 Vdc unregulated
Power Consumption : 1,2 Watt
B.1.3 GPS PERFORMANCE
Geodetic Datum : WGS84
Channels : 12 parallel Channels
Frequency : 1575.42MHz (L1, C/A code)
