39
User Manual
this mode is set the maps are displayed in order to use colors as similar as possible to
the ones used in the original paper charts. Classic uses more vivid colors. Night
Vision is recommended when the environment is dark in order to reduce the glare
of the display. The chartplotter displays maps and screen in darker colors. Sunlight
is designed to enhance the visibility of the screen when the chartplotter is exposed to
the sunlight. The maps are much brighter than in the other modes and the depth
areas are filled with white color so different depth areas are not easily distinguish-
able. NOAA allows setting NOAA paper chart colors presentation.
3.5.1.3 Map Orientation
'MENU' + "MAP SETTINGS" +'ENTER' + "Map Orientation" + 'ENTER'
Selects the orientation of your chart according to: North (the map is shown
with North upwards), Head (the map is shown with the ship's current heading up-
wards), Course (the map is displayed with the currently selected course leg upwards).
The default setting is North
It is possible to select the resolution angle for the Map Orientation.
3.5.1.4 Zoom Type
'MENU' + "MAP SETTINGS" +'ENTER' + " Zoom Type" + 'ENTER'
This feature allows more expansions or compression of the chart scale while
zooming in or out. Zoom Mode has two options; STANDARD (default) or FLEXI-
ZOOM. When in FLEXI-ZOOM mode, a short 'ZOOM...' push causes a change of
chart, whilst a long 'ZOOM...' push (press and hold) causes a pop-up window to be
displayed on a corner of the screen. The window shows the current Zoom Factor.
By pressing 'ZOOM IN'/'ZOOM OUT' the map is expanded or compressed
according to the zoom factor selected.
The Window is automatically closed if 'ZOOM...' is not pressed for 2 sec-
onds and the selected zoom factor will be used at the next zoom in/out.
3.5.1.5 Fonts & Symbols
'MENU' + "MAP SETTINGS" +'ENTER' + "Fonts & Symbols" + 'ENTER'
On MAX charts it is possible to set the size of all names and symbols drawn on
the charts, selecting between Normal size (the regular characters size) and Large size.
