32 User Manual
3.2.6 UNITS SELECTION
Allows to select the preferred unit for Distance, Speed, Depth and Altitude
(altitude of GPS Antenna on the medium sea level).
Speed: Kts(knots)/Mph(miles per hour)/Kph(chilometres per hour). The default set-
ting is Kts.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "SPEED" + 'ENTER'
Distance: Nm(Nautical Miles)/Sm(statute miles)/Km(chilometres). The default setting
is Nm.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "DISTANCE" + 'ENTER'
Depth: Ft(Feet)/FM(Fathoms)/Mt(Meters). The default setting is Ft.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "DEPTH" + 'ENTER'
Altitude: Ft(Feet)/FL(Flight Level)/Mt(Meters). The default setting is Ft.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "ALTITUDE" + 'ENTER'
Temperature: °C/°F. The default setting is °C.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "TEMPERATURE" + 'ENTER'
3.2.7 NAV AIDS PRESENTATION
Allows to set the Nav Aids presentation as US or INTERNATIONAL. The
default setting is INTERNATIONAL. When selected it affects Lights, Signals, Buoys
& Beacons display.
- INT(International): Draws Nav-Aids using international symbology. All
components of Complex Objects are shown.
- US: Draw Nav-Aids using NOAA symbology. All components of Com-
plex Objects are shown.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "NAV AIDS PRESENTATION" +
'ENTER'
3.2.8 INPUT/OUTPUT MENU
3.2.8.1 Port 1/Port 2/Port 3 Input
Sets or disables the format for the navigation data input serial Port1/2/3.
The default setting is NMEA-0183 4800-N81-N. For example to set the Port 2 as
NMEA-0183 (4800 Baud Rate, Parity None, 8 Bits Number, 1 Stop Bit and Normal
Polarity) you must select:
