Lorenz Compact 7 Plus - 2 Before You Begin; The Keyboard

17
User Manual
2
Before You Begin
This chapter provides basic information to get you start using the chartplotter;
it will help you to become familiar with the chart display and the functions of the
controls before you start using the chartplotter.
2.1 THE KEYBOARD
The 'CONTRAST'/'BACKLIGHT'/'POWER' key
Press and hold the right side of 'POWER' for 1 second to turn the chartplotter
On. Press and hold the right side of 'POWER' down (once the chartplotter has been
turned On) for 3 seconds turns the chartplotter Off.
Press and immediately release the right side of 'POWER' to adjust the back-
light, press and immediately release the left side of 'POWER' to adjust the contrast
of the display.
The key
Press 'MENU' to select the Functions Menu.
The key
Place the cursor and press 'GO-TO' to set Target.
The key
Press 'PAGE' to select the configuration you wish among cartography and
text area in two different modes (text area on the right side or on the bottom line of
the screen, full screen if Target has been inserted or with partial information on
SOG), only cartography, Depth Graph 1/2 screen and 1/3 screen pages, GPS Data
page, Navigation Data page, Graphic Data page.
The key
Press 'MODE' to set the Navigate mode (Home)
