42 User Manual
3.5.1.10 Other Map Configurations
'MENU' + "MAP SETTINGS" +'ENTER' + "Other Map Configurations" + 'ENTER'
This function allows the user to customize the following selections and is
divided into the following setting: Marine Settings, Depth Settings, Land Settings
and Chart Settings.
Display Mode: To simplify the customization of the chart display, the map settings
are now re-organized in modes allowing the user to choose the preferred setting. Pre-
programmed settings are user selectable from Full, Medium, Low, Radar, Tides,
Custom. The default setting is Custom.
'MENU' + "MAP SETTINGS" +'ENTER' + "Other Map Configurations" + 'ENTER'
+ "Display Mode" + 'ENTER'
The table below shows the selections for each mode:
Setting Full Medium Low Radar Tides Custom
(Default values)
Names On On On On On On
Buoys Name On Off Off Off Off On
Nav-Aids On On On On Off On
Light Sectors On Off Off Off Off On
Attention Areas On On Off Off Off On
Tides & Currents On Off Off Off On On
Seabed Type On Off Off Off Off On
Ports & Services On On Off On Off On
Tracks & Routes On Off Off Off Off On
Underwater Objects On On Off Off Off On
Depth Range On On On Off On On
Depth Range Min 3 Mt 3 Mt 3 Mt 3 Mt 3 Mt 3 Mt
Depth Range Max 10 Mt 10 Mt 10 Mt 10 Mt 10 Mt 10 Mt
Rocks > 0 Mt 0 Mt 0 Mt 0 Mt 0 Mt 0 Mt
Rocks < 9999Mt 5 Mt 5 Mt 5 Mt 5 Mt 9999Mt
Land Elevation Data On Off Off Off Off On
Roads On Off Off Off Off On
POIs On Off Off Off Off On
Lat/Lon Grid On Off Off Off Off On
Chart Boundaries On Auto Off Off Off Auto
Mixing Levels On Off Off Off Off Off
Value Added Data On Off Off Off Off On
Names: On/Off. The default setting is On.
'MENU' + "MAP SETTINGS" +'ENTER' + "Other Map Configurations" + 'ENTER'
+ "Names" + 'ENTER'
Buoys Name: On/Off. The default setting is On. To identify better the Buoys, the
name/number of the buoys is shown next to the icon on the chart.
