68 User Manual
4.3.2 DELETING THE A-B-C-D POINTS
When placing the cursor on the desired point (A, B, C or D) the information
window appears. Press 'ENTER', select "DELETE" and press 'ENTER' again: the
point is deleted. When the point is deleted, the cursor is placed on the previous
point, if existed. The labels of the next points are renamed.
4.3.3 DELETING THE A-B-C-D SEGMENT
When placing the cursor on the desired point (A, B, C or D) or on segment
between two points the information window appears. Press 'ENTER', select "DELETE
ALL" and press 'ENTER' again: all points and connecting segments are deleted.
4.3.4 MOVING THE A-B-C-D POINTS
When placing the cursor on the desired point (A, B, C or D) the information
window appears. Press 'ENTER', select "MOVE" and press 'ENTER': by the cursor
key move the cursor, on the screen a dotted line connecting the point to move with the
new position appears. By pressing 'ENTER' the point is placing in the new position.
4.3.5 INSERTING THE A-B-C-D POINTS
Placing cursor on the segment connecting two points, the information win-
dow appears. Select "INSERT" and press 'ENTER': by the cursor key move the
cursor, on the screen a dotted line appears. By pressing 'ENTER' the new point is
placing between the two existed points which are renamed.
4.3.6 NAVIGATING ON THE A-B-C-D POINTS
If fix received is good, place the cursor on the desired point A, B, C or D and
press 'GO-TO'. When ship reaches the Destination point, navigation follows the
next point (if exists). When Target is set, three options are available: STOP NAV,
NEXT and PREV.
4.4 USING THE TRACK FUNCTIONS
The chartplotter can be set up for recording your track as you move and for
plotting this track on the chart.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER'
