84 User Manual
5.4.1 BEARINGS
Selects either degrees magnetic or true. If magnetic readings are selected the
variation is computed automatically for every zone as soon as the chart is displayed.
The default setting is Mag.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "COMPASS" + 'ENTER' +
"BEARINGS" + 'ENTER'
5.4.2 VARIATION
It is possible to calculate the Magnetic Variation in an Automatic or manual
mode, by inserting the step for calculation of Magnetic Variation. The default set-
ting is Automatic.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "COMPASS" + 'ENTER' +
"VARIATION" + 'ENTER'
5.4.3 CALIBRATION
The variation table is used to match magnetic value readout on the chartplotter
comparable with the value given by the compass of the boat. In other words, since
the compass of the boat must be compensated (due to the iron masses, ...), we use the
same values given by the chartplotter. This means that, for example, if the BRG to
the next Waypoint readout in the chartplotter display is "X" Mag degree, if you steer
the boat reading "X" Mag degree from the compass, you are driving well toward the
next Waypoint.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "COMPASS" + 'ENTER' +
"CALIBRATION" + 'ENTER'
5.5 ALARMS
The chartplotter provides alarm settings for various functions. Here you can
set the system for your navigational requirements.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "ALARMS" + 'ENTER'
5.5.1 ARRIVAL ALARM
Specifies the radius of a circle around the Waypoint of a route: when your
vessel reaches this circle the alarm sounds. You can disable (Off) the Arrival Alarm
or insert value. The default setting is 1.00 Nm.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "ALARMS" + 'ENTER' + "AR-
RIVAL ALARM" + 'ENTER'
