4.4.1 SELECTING ACTIVE TRACK
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' + "AC-
TIVE TRK" + 'ENTER'
Select the number of the active track. The default setting is 1.
4.4.2 ENABLING TRACK STORING
'MENU' + "CONFIGURAZIONI SPECIALI" + 'ENTER' + "TRACCIA" + 'ENTER'
+ "TRACCIA" + 'ENTER'
To enable (On) or disable (Off) the track storing. It is not possible to use the
track storing if you are not receiving a valid fix. The default setting is On.
4.4.3 DISPLAYING TRACK
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' + "VIS-
IBLE" + 'ENTER'
To enable (On) or disable (Off) the displaying of track. The default setting is
Off.
4.4.4 SELECTING TRACK LINE PATTERN
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' + "LINE
PATTERN" + 'ENTER'
Selects the desired line pattern for the selected track.
Note FOR COLOR CHARTPLOTTER
"LINE PATTERN" item is substitued by the "COLOR" item, to select the desired color among
the eight colors available for the selected track.
4.4.5 DELETING TRACK
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' + "DIS-
TANCE" + 'ENTER'
Deletes all track. After pressing 'ENTER' a warning window appears: select
"Yes" and press 'ENTER' to confirm (select "No" otherwise).
4.4.6 DELETING SELECTED TRACK
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "TRACK" + 'ENTER' +
"DELETE SELECTION" + 'ENTER'
Deletes the track selected. After pressing 'ENTER' a window appears: press
'ENTER' to set the first point , then press 'ENTER' to set the second point. A
warning window appears: select "Yes" and press 'ENTER' to confirm the deletion
