Lorenz Compact 7 Plus - Map Datum; Map Orientation and Resolution; Rolling Road Scale; Reset Total and Partial Trip

83
User Manual
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "NAVIGATE" + 'ENTER' +
"FIX DATUM" + 'ENTER'
5.3.3 MAP DATUM
Selects the Map Datum among 130 items. WGS-84 is the default Fix Datum.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "NAVIGATE" + 'ENTER' +
"MAP DATUM" + 'ENTER'
5.3.4 MAP ORIENTATION AND RESOLUTION
Selects the orientation of your chart according to your personal needs (see
Par. 3.5.1.3 for more information). The Orientation Resolution is the resolution
angle for the Map Orientation, range [5, 60] degrees. The default setting is 30°.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "NAVIGATE" + 'ENTER' +
"ORIENT. RESOLUTION" + 'ENTER'
5.3.5 ROLLING ROAD SCALE
Sets you preferred Rolling Road Scale among 0.2, 0.5, 1.0, 2.0, 4.0, 10.0. The
default setting is 0.2.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "NAVIGATE" + 'ENTER' +
"ROLL ROAD SCALE" + 'ENTER'
5.3.6 RESET TOTAL AND PARTIAL TRIP
Resets the partial or total distance traveled by the ship from the first activa-
tion of the chartplotter or starting from the values reset. The partial or total trip
value is shown on the top of the Navigation Page.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "NAVIGATE" + 'ENTER' +
"RESET PARTIAL TRIP" + 'ENTER'
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "NAVIGATE" + 'ENTER' +
"RESET TOTAL TRIP" + 'ENTER'
5.4 COMPASS
The Compass menu sets the desired value for Bearing and Magnetic Varia-
tion, and selects the Compass Calibration page.
'MENU' + "ADVANCED SETTINGS" + 'ENTER' + "COMPASS" + 'ENTER'
