Lorenz Compact 7 Plus - 3.2 BASIC SETTINGS

33
User Manual
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"PORT 2 INPUT" + 'ENTER'+ "NMEA-0183 4800-N81-N" + 'ENTER'
Note
The option C-COM defines on which Port (both Input and Output) the C-COM modem is connected.
It is important to remark that this setting affects the Input and the Output of the selected Port. C-COM
can only be set on one Port at time. If C-COM was already assigned to a Port and the user tries to
set the C-COM to another Port, the chart plotter will show a message that warns the user about the
current settings and asks if the new settings must overwrite the previous ones.
3.2.8.2 Port 1/Port 2/Port 3 Output
Sets or disables the output interface. The default setting is NMEA-0183 4800-
N81-N. For example to set the Port 2 as NMEA-0180 you must select:
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"PORT 2 OUTPUT" + 'ENTER'+ "NMEA-0180" + 'ENTER'
Note
Selecting NMEA-0180 or NMEA-0180CDX the chart plotter shows a message to advise the user
that the related input will be disabled.
3.2.8.3 Port 1/Port 2/Port 3 NMEA Output Messages Selection
The chart plotter allows customizing the NMEA-0183 sentence transmitted
on each port. The default setting is GLL, VTG, XTE, RMB, RMC, APB On and
BOD, BWC, RMA, WCV, GGA, HSL , HDG Off.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"PORT 1/2/3 OUTPUT SENTENCES" + 'ENTER'
3.2.8.4 GPS Setup Menu
It is possible to set the your preferred configuration for the connected GPS.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"GPS SETUP" + 'ENTER'
Note
This item is shown alternately to the selection of the output messages when to the related port is
connected a GPS identificable by the chart plotter.
Internal GPS FOR CHARTPLOTTER WITH INTERNAL GPS RECEIVER
Enables (On) or disables (Off) the Internal GPS. The default setting is On.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"GPS SETUP" + 'ENTER' + "INTERNAL GPS" + 'ENTER'
Restart GPS
Restars all GPS processes. Once executed, the message "Done" is shown.
'MENU' + "BASIC SETTINGS" + 'ENTER' + "INPUT/OUTPUT" + 'ENTER' +
"GPS SETUP" + 'ENTER' + "RESTART GPS" + 'ENTER'
