1. if there is a C-CARD inserted in the slot and there is not a malfunction, the
name of the C-CARD zone and the message "OK" are shown.
2. if there is a C-CARD inserted in the slot, but it is a damaged C-CARD, the
name of the C-CARD zone and the message "Faulty" are shown.
3. if there is not any C-CARD inserted in the slot, the message "not present" is
shown.
4. if there is an User C-CARD inserted in the slot, the message "USER C-CARD"
is shown.
C-CARD Connector
Indicates if there is a malfunction in the connector. It is used only in production.
6.6.4 SERIAL PORTS
If you are having problems receiving data from the position-finding instru-
ment, this test should help determine the problem.
Change Parameters
Allows to change the parameters of the serial interface. This menu allows to
select the Port (Signal Source) between Port 1, Port 2 or Port 3, the Baud Rate
between 4800 or 9600, the Data Bits (Word Length) between 7 or 8, the Parity
between even, odd or none, the Stop Bits between 1 or 2.
Input Data Display
Allows the chartplotter to act as a computer terminal and display the incoming
data exactly as it received.
If the data displayed on the screen is unrecognizable, you may have selected the
wrong input parameters for your particular receiver. Check your receiver manual
to be sure that you have selected the proper interface format. If the screen is
blank, you may have a broken connection and no data is being received.
Use 'ZOOM IN' to stop (or continue after pause) data displaying, 'ENTER' to
show data in hex or ASCII mode (normal or small) and 'CLEAR' to exit.
6.6.5 MODEM TEST
To check the Modem connections. Press 'ENTER' to select the preferred
Port (Port 1 or Port 2
FOR
CHARTPLOTTER
WITH
INTERNAL
GPS
RECEIVER
, Port 1, Port
2 or Port 3
FOR
CHARTPLOTTER
WITH
EXTERNAL
GPS
RECEIVER
) related to the connec-
tions made, to the Port that the Modem C-COM is connected.
