Replacing
the
Hard
Drive
18
T
o
install
a
new
hard
drive:
1.
Insert
the
2
hard
drive
screws
closest
to
the
SA
T
A
and
power
ports
on
the
hard
drive
and
tighten
them
half
way
.
2.
Power
off
the
system,
and
unplug
all
cabling
from
the
system.
3.
T
urn
the
recorder
over.
Remove
the
bottom
panel
screws
(6×).
#LX40011
1;
r
.
3.0/56507/56507;
en-US
84
91
93
