LH060 Series System
Specifications
23
System
Operating System Linux (embedded)
Pentaplex Simultaneous view, record, playback, backup & re-
mote monitoring
Number of Channels
4 channels
Inputs/Ouputs
Video IN 4 Channels (via USB)
Video OUT None
VGA OUT Yes
HDMI Yes
Audio IN None
Audio OUT None
USB Port 2x USB 2.0 (one on front panel, one on back
panel)
Alarm IN None
Alarm OUT
None
Video Output Resolution
1920×1080, 1280×1024, 1280×720, 1024×768,
1440×900
PTZ Control
None
Display
Display Split
1, 4
Live Display Speed Max 10fps
OSD Camera Title, Time, Motion Detection, Recording
Status
System Navigation USB mouse, IR remote controller
Motion Area Setting Not adjustable, default for all motion area
Sensitivity Levels Low/Medium/High
Firmware Upgrade Automatic over the Internet & via USB device and
network
User Authority By user group
Time Synchronization
Auto time sync by NTP server
Recording
Video Compression
H.264
Recording Resolution 1080p (1920×1072)
Recording Rate Max 10fps
Recording Resolution Setting
None
Recording Quality Control 3 levels (Low/Medium/High)
Recording Schedule By hour, by day, by recording mode, by motion, by
channel
Pre Recording Max. 10 seconds
Post Recording Max. 5 minutes
#LX400080; r.36800/36800; en-US
154
