Replacing the Hard Drive20
4. Next, remove the hard drive from the housing. This step depends on if you are using a
3.5” or 2.5” hard drive:
If your system has a 3.5” hard drive:
4.1. Turn the DVR over carefully and loosen the 4 screws securing the hard drive.
4.2. Turn the DVR back over and slide the hard drive and lift out of the DVR.
4.3. Remove the 4 screws on the bottom of the hard drive.
If your system has a 2.5" hard drive:
4.1. Turn the DVR over carefully. Hold the hard drive in place and remove the 4
screws securing the hard drive. Keep holding the hard drive and turn the DVR
back over. Remove the hard drive from the DVR.
WARNING
Make sure to hold the hard drive in place while removing the hard drive screws and turning
the DVR to avoid damaging the DVR.
1. Replace the side and cover panel screws.
20.2 Installing the Hard Drive
WARNING
Make sure that the power cable has been disconnected before changing the hard drive.
1. Remove the screw from each side panel and rear panel (x3) of the cover.
2. Gently slide the cover away from the rear panel and lift off. Be careful of sharp edges.
#LX400080; r.36800/36800; en-US
141
