Basic Setup (LH060 Series)
5
5.4 Step 5: Connect the Monitor
• Connect the included HDMI cable from the HDMI port to the TV or monitor (recommended) OR;
• Connect a VGA cable (not included) from the VGA port to the monitor.
5.5 Step 6: Connect the Power Adapter and Turn On the DVR
• Connect the included power adapter to the DC 12V port. Connect the end of the power adapter to a
wall socket or a surge protector.
At startup, the system performs a basic system check and runs an initial loading sequence.
After a few moments, the system loads a live display view.
5.6 Step 8: Upgrade Firmware to Latest Version (if Available)
If a firmware upgrade is available, you will be asked to install it once the DVR starts up. It is
required to upgrade your system firmware and client software or mobile apps to the latest
version to enable remote connection to the system.
#LX400080; r.36800/36800; en-US
