32
Using the Main Menu
Confirming Backup
To verify that the file has been properly backed
up:
1. Click to open Event List.
2. Click from the Smart Search event
filter.
3. Select the file and click . The backup
file should begin playing.
4. To exit, right-click until you return to the
main scr
een.
Backup File Information
Backup files are saved as MOV files. These
files can be played on the system using Event
List or on your PC using QuickTime Player. See
“Event List” on page 17.
Backup files are labeled according to the
following naming convention:
ch_##YYYYMMDDhhmmss.mov:
For more details on viewing backup files, see
“Appendix H: Playing Saved Video” on page 71.
LAN
Configure network settings.
From the Main Menu, click . The LAN
menu opens.
NOTE:
Some networking knowledge is required
when adjusting options in the LAN menu.
To configure network settings:
1. Select the following, and use the
scroll-wheel to change v
alues:
• IP
• Mask
• Gateway
• DHCP (8
/16-channel
only
)
• HTTP Port
• QuickTime HTTP Port (4-channel
only
)
2. To save your settings, right-click until you
return to the
main screen.
NOTE:
DCHP allows you to quickly connect to
your network by obtaining an IP address from
the router. After the initial setup, we recommend
that you disable DHCP and set the IP address
between 1~100. For example, if your IP address
is 192.168.0.107, change the last digits to 90 (i.e.
192.163.0.90). This ensures that port forwarding
will not change in the event of power failure or
resetting of your network.
NOTE: For added security, we strongly
recommend changing HTTP port 80 on the
system to
any desired port
not blocked by your
Internet service provider (ISP). For details on
changing ports on your system, see “Appendix
C: Changing Ports On Yo
ur
System” on page 61.
Filename Definition
ch_## Channel number (1~4)
YYYY Year
MM Month
DD Day
hh Hour
mm Minute
ss Second
