Getting Started
Remote Control
The remote control is the secondary input device
for navigating the system’s graphical user
interface.
NOTE:
If the remote control included with your
system differs from figure 3.0, please see page 6
for details.
To use the remote control:
1. LIST: Open the Event List menu.
2.
OSD: Show/hide the on-screen display.
3. Primary controls:
• MENU: Opens the system main menu.
• : Press to open the Split-Screen Selection
menu (
8 / 16-channel only
).
From full-screen single channel view, changes
display
view to Quad split-screen (
4-channel
model only
)
• S/
CH+: Move cursor in menus up; Channel Up.
• X/FWD: Move cursor in menus right; during
playback, increase forward playback speed (5X,
15X, 60X).
• W/
REW: Move cursor in menus left; during
playback, increase reverse playback speed (5X,
15X, 60X)
•
/: Start/pause forward playback.
• T/CH-: Move cursor in menus down; Channel down.
•
ESC: Go back / exit menus.
• : Confirm menu selections.
4. : While in Event List menu, press to delete a selected event (no confirm or undo).
5.
: During Live Mode and Playback, press to switch between cameras (4-channel); Press to
take a screenshot of the main display—USB flash drive mus
t be connected (8/16-channel
only).
6. Increase/Decrease buttons:
• : Increase the value of selected menu option.
• : Decrease the value of selected menu option.
*Remote control included with the system may vary depending on model.
Figure 3.0 Remote Control
1
2
3
4
5
6
*
