49
APPENDIX A: SYSTEM SPECIFICATIONS
Specifications are shared among 4/8/16-channel models unless specifically noted.
DVR
Description Specification
4CH 8CH 16CH
Hard disk capacity Maximum 1 HDD up to 1TB, 100% duty cycle
Operating system Linux (embedded)
Backup USB flash drive (front panel port
only
)
Backup file format MOV
Compression H.264
Recording
resolution
NTSC: 640x240, 640x480; PAL: 640x256, 640x512
Recording speed 60 fps (NTSC)/50 fps (PAL) @
640x240/640x256 NTSC/PAL
120 fps (NTSC) / 100 fps (PAL)
Recording schedule Daily, Weekly—adjust specific hour per channel
Pre/Post alarm
recording
3~10 sec. (pre); 1~255 sec. (post)—programmable per camera
Event/Log search Up to 4096 for alarm, motion, video loss, power loss
Playback Single, Quad Single, Quad, 8-channel
simultaneous
Single, Quad, 8,
16-channel simultaneous
Video inputs 4 x 1Vp-p, 0.75 ohms, BNC 8 x 1Vp-p, 0.75 ohms,
BNC
16 x 1Vp-p, 0.75 ohms,
BNC
Video outputs 1 x VGA 1 x DVI
Audio inputs 2 x line-in, RCA
Audio outputs 2 x line-out, RCA
Supply voltage 120 VAC-240 VAC, 12V DC, 2.5 A,
50/60 Hz
120 VAC-240 VAC, 12V DC, 3 A, 50/60 Hz
Power consumption Approximately. 30 watts
Operating Temp
Range
41
º~104º F / 5º~40º C
