70
APPENDIX G: CONNECTING AUDIO
You can listen to, and record live audio on the system one channel at a time.
To connect audio:
1. Connect RCA audio cables from an audio capable camera(s) to the AUDIO IN 1 / 2 ports on the
re
ar panel.
2. Connect RCA audio out cables to the AUDIO OUT ports on the rear panel.
NOTE: The
audio-out ports are two separate
mono
channels,
not
stereo left and right.
3. From the system Main Menu, click .
4. Click Aud
io, and then click under each c
amera and select either O to enable audio or X to
disable audio.
NOTE:
Audio is only available on channels 1 and 2.
LINE AUDIO / AMPLIFIED SPEAKERS
(not included)
DVR
AUDIO CAPABLE CAMERAS
(not included)
